No.	Code	Size (+- 3%) mm			Pallet Weight (+- 5%) Kgs. Without Steel	Pallet Weight (+- 5%) Kgs. With Steel	Steel Reinforced (BARS)	Loading Capacity (Ton)
No.	Code	Size (+- 3%) mm			Pallet Weight (+- 5%) Kgs. Without Steel	Pallet Weight (+- 5%) Kgs. With Steel	Steel Reinforced (BARS)	STATIC	DYN	RACKING
1	F-REV-WLD-A-1008(15)	1000	800	15	14.52	19.5	8	6	2	1.6
2	F-REV-WLD-A-1010(15)	1000	1000	15	16	21	8	6	2	1.6
3	F-REV-WLD-A-1109(15)	1100	900	15	17	22	8	6	2	1.6
4	F-REV-WLD-A-1111(15)	1100	1100	15	20	27	8	6	2	1.6
5	F-REV-WLD-A-1210(15)	1200	1000	15	22.5	28.5	8	6	2	1.6
6	F-REV-WLD-A-1211(15)	1200	1100	15	22.7	29.7	8	6	2	1.6
7	F-REV-WLD-A-1212(15)	1200	1200	15	25.8	33.3	8	6	2	1.6
8	F-REV-WLD-A-1311(15)	1300	1100	15	27.8	35.8	8	6	2	1.6
9	F-REV-WLD-A-1412(15)	1400	1200	15	27.5	35.5	8	6	2	1.6

Search

Flat Reversed Welded
